Micronic Microphones

Regular price £4.99 Sale

The Panasonic WM-61A microphone capsule is a very popular and small 6mm diameter electret condenser for general purpose use. As standard wired directly to any compatible device this microphone will most definitely improve sound. Also renowned for its use with the Linkwitz modification for DIY recording projects as shown in our photo
Features
Back electret type designed for high resistance to vibrations
High sensitivity, high signal to noise ratio
Solder type for lead wires

Specifications
Model:  WM-61A
Manufacturer: Panasonic
Diameter: 6.0mm
Height: 3.4mm
Impedance: Less than 2.2KΩ
Directivity: Omni-directional
Frequency: 20-20,000Hz
Max. Operation Voltage: 10V
Standard Operation Voltage: 2V
Current consumption: Max.0.5mA
Sensitivity reduction: within-3dB at 1.5V
S/N ratio: More than 62dB
Sensitivity: -35±3dB (0dB/pA,1KHz)
